Next-Gen Hybrid Power

Mobile Hybrid Power Stations

MPMC Mobile Hybrid Power Station is a high-efficiency off-grid solution integrating a Diesel Genset, Solar PV, Lithium Battery Storage, and Smart EMS. Tailored for equipment rental fleets, infrastructure, mining, and project sites, the system utilizes the battery to handle peak and light loads, starting the diesel generator only when needed to power the load and recharge at peak efficiency. This hybrid operation saves up to 80% on fuel, substantially cuts emissions, maintenance costs, and engine runtime, while delivering whisper-quiet power ideal for night construction, events, and residential areas.

Up to 80%
Fuel Consumption Cut
0 ms
Seamless Power Switch
1,000 hrs
Extended Service Cycle
🛡️
IP54 / IP55 Rated

Heavy-Duty All-Weather Enclosure

🇪🇺
CE Certified

EMC & LVD Directive Compliance

🇦🇺
Australia RCM

Electrical Safety Standard Certified

MPMC Mobile Hybrid Power Station in Operation
⚡

Solar-Diesel-Battery

All-in-One Microgrid Station

Proven Efficiency

Why Choose Mobile Hybrid Power Stations?

Traditional generators waste fuel running under light and variable loads. MPMC Hybrid Stations optimize energy dispatch, eliminate engine idling, and slash carbon emissions.

⛽

Massive Fuel Savings

Energy storage handles base and peak loads, allowing the diesel generator to run only at its peak efficiency zone or switch off entirely, saving up to 80% in fuel.

🔇

Silent & Clean Night Ops

Operate in 100% pure battery mode during nighttime, urban construction, or quiet hours. Eliminates noise complaints, localized exhaust emissions, and night-shift disruptions.

⚙️

4x Longer Service Cycles

Drastically reduces engine run-hours and prevents wet-stacking caused by light-load idling. Maintenance intervals extend to over 1,000 hours, cutting OPEX dramatically.

🚀

All-in-One Fast Deployment

Self-contained plug-and-play architecture with integrated solar PV wings, LiFePO4 battery, Tier-3/Stage-V genset, and DSE EMS for rapid field deployment anywhere.

Solar-Diesel-Storage Integration

MPMC GSB Series (Solar + Diesel + Battery)

Engineered with deployable 2,550Wp foldable solar wings, industrial diesel genset, LiFePO4 battery storage, and smart EMS for ultra-clean mobile power.

⚙️ GSB Series Intelligent Operating Logic

Automated multi-source energy prioritization managed by smart DSE Hybrid Controller:

1
Solar & Battery Priority
Solar PV and LiFePO4 storage supply 100% clean, silent energy under light to medium loads.
2
Peak Load Shaving
Battery instantly discharges to handle sudden motor-start spikes without stressing the engine.
3
Optimized Genset Start
Genset auto-starts only when battery hits low SOC, running strictly at optimal 80-90% load.
4
Fast Dual Recharge
Excess generator output and solar power rapidly recharge the battery, then genset shuts off.
Foldable Solar 2550Wp MPMC GSB-20-40 Solar Diesel Hybrid Power Station

GSB-20-40

Solar + Diesel + Battery Hybrid
⚡ Genset: 20 kVA
🔋 Battery: 40.9 kWh
☀️ Solar: 2,550 Wp
  • 2,550Wp integrated hydraulic foldable solar array
  • Ultra-low noise canopy with DSE smart hybrid controller
  • 0ms seamless automatic microgrid power switch
  • Ideal for compact telecom base stations & mobile security
Foldable Solar 2550Wp MPMC GSB-30-60 Solar Diesel Hybrid Power Station

GSB-30-60

Solar + Diesel + Battery Hybrid
⚡ Genset: 30 kVA
🔋 Battery: 61.4 kWh
☀️ Solar: 2,550 Wp
  • 61.4kWh high-safety LiFePO4 liquid-cooled energy storage
  • Heavy-duty IP54 weather-proof soundproof enclosure
  • Smart EMS real-time remote cloud monitoring & telemetry
  • Tailored for construction lighting, night ops & events
Foldable Solar 2550Wp
CE (EMC/LVD) RCM
MPMC GSB-30-90 Solar Diesel Hybrid Power Station

GSB-30-90

Solar + Diesel + Battery Hybrid
⚡ Genset: 30 kVA
🔋 Battery: 91.4 kWh
☀️ Solar: 2,550 Wp
  • 91.4kWh extended capacity LiFePO4 battery pack
  • Full international compliance: EMC, LVD and Australia RCM
  • Up to 90% fuel reduction during night and low-load cycles
  • Perfect for highway construction, urban works & remote camps
Foldable Solar 2550Wp MPMC GSB-40-60 Solar Diesel Hybrid Power Station

GSB-40-60

Solar + Diesel + Battery Hybrid
⚡ Genset: 40 kVA
🔋 Battery: 61.4 kWh
☀️ Solar: 2,550 Wp
  • 40kVA industrial prime diesel engine with electronic governor
  • Heavy crane lifting lugs and forklift pockets for rapid mobility
  • Low-temperature battery thermal management system
  • Engineered for equipment rental fleets & civil engineering
Foldable Solar 2550Wp
CE (EMC/LVD) RCM
MPMC GSB-40-90 Solar Diesel Hybrid Power Station

GSB-40-90

Solar + Diesel + Battery Hybrid
⚡ Genset: 40 kVA
🔋 Battery: 91.4 kWh
☀️ Solar: 2,550 Wp
  • 40kVA genset + 91.4kWh high-capacity LiFePO4 battery
  • Certified to EMC, LVD and Australian RCM electrical standards
  • 0ms seamless UPS-grade power changeover capability
  • Standard fleet choice for mining camps & remote off-grid sites
Foldable Solar 2550Wp
RCM Certified
MPMC GSB-50-90 Solar Diesel Hybrid Power Station

GSB-50-90

Solar + Diesel + Battery Hybrid
⚡ Genset: 50 kVA
🔋 Battery: 91.4 kWh
☀️ Solar: 2,550 Wp
  • 50kVA high-output prime diesel power station
  • Fully compliant with Australian Standard RCM certification
  • Heavy-duty dual-axis towable trailer option available
  • Built for heavy drilling, quarry sites & commercial rentals
Diesel-Storage All-in-One Integration

MPMC GB Series (Diesel + Battery Integrated)

Heavy-duty, container-optimized hybrid stations for unmanned operations, rental fleets, high-power mining, and industrial infrastructure.

⚡ GB Series Intelligent Operating Logic

Smart automated energy management with external solar expansion and quick-connect interfaces:

1
Smart Battery Baseload
Battery handles baseload & overnight quiet periods; diesel genset remains completely shut down.
2
0ms Seamless Shaving
High-rate battery instantly injects surge power during heavy equipment startup, avoiding dips.
3
Peak-Efficiency Dispatch
Genset runs strictly within its 80-90% fuel-efficiency sweet spot, recharging battery simultaneously.
4
External Solar Expansion
Direct plug-and-play ports for 75kWp–300kWp external solar containers to achieve zero fuel cost.
Container Fit: 8 Units / 40'HC
CE (EMC/LVD) RCM
MPMC GB-30-90 Diesel Battery Hybrid Power Station

GB-30-90

Diesel + Battery Integrated Station
⚡ Genset: 30 kVA
🔋 Battery: 91.4 kWh
☀️ Ext. Solar: 75 kWp MPPT
  • 30kVA industrial prime diesel engine + 91.4kWh LiFePO4 battery
  • CE Certified (EMC & LVD Directives) & Australia RCM Certified
  • Standard 125A CEE industrial quick-connect input/output sockets
  • Up to 8 units loaded per 40'HC container for ultra-low logistics cost
  • Engineered for rental fleets, unmanned telecom towers & infrastructure
Heavy Duty / Rental Fleet
CE (EMC/LVD) RCM
MPMC GB-40-90 Diesel Battery Hybrid Power Station

GB-40-90

Diesel + Battery Integrated Station
⚡ Genset: 40 kVA
🔋 Battery: 91.4 kWh
☀️ Ext. Solar: 75 kWp MPPT
  • 40kVA prime power genset paired with 91.4kWh high-density storage
  • Full CE (EMC/LVD) compliance and Australian Standard RCM verified
  • 0ms seamless microgrid power switch with DSE hybrid management
  • 1,000+ hours maintenance intervals, slashing on-site service trips
  • Designed for heavy construction, mining operations & commercial rental
Australian Standard Compliant
RCM Certified
MPMC GB-50-90 Diesel Battery Hybrid Power Station

GB-50-90

Diesel + Battery Integrated Station
⚡ Genset: 50 kVA
🔋 Battery: 91.4 kWh
☀️ Ext. Solar: 75 kWp MPPT
  • 50kVA heavy-duty diesel genset + 91.4kWh LiFePO4 battery system
  • Fully compliant with Australian Standard RCM safety certification
  • High-efficiency MPPT solar charge controller for remote field arrays
  • Robust IP54 heavy-gauge steel enclosure for extreme ambient conditions
  • Ideal for mining camps, regional infrastructure & heavy equipment fleets
Megawatt Heavy-Duty
ISO 8528 / IEC
MPMC GB-150-170 Megawatt-Class Hybrid Power Station

GB-150-170

Megawatt-Class Hybrid Power Station
⚡ Genset: 150 kVA
🔋 Battery: 173 kWh
☀️ Ext. Solar: 300 kWp MPPT
  • 150kVA prime heavy diesel generator + 173kWh liquid-cooled storage
  • High-capacity 300kWp external solar container plug-and-play port
  • Heavy industrial 250A Powerlock quick-connect busbar terminals
  • Multi-unit parallel synchronization capability up to Megawatt scale
  • Built for mega infrastructure projects, deep mining & festival microgrids
Global Track Record

Proven Field Reliability Worldwide

Explore how MPMC Hybrid Power Stations deliver extreme fuel economy, zero-downtime reliability, and whisper-quiet power across 120+ countries and harsh environments.

Spain MPMC Hybrid Power in Spain Solar Project

Spain • Solar Construction & Infrastructure

Deployed on high-irradiance solar farm construction sites. Daytime solar and battery handle baseload and site office HVAC, slashing generator runtime by 82%.

Fuel Saved

82% Saved

Noise Level

< 58 dBA @ 7m

France MPMC Hybrid Power Station in France Urban Project

France • Urban Low-Emission Night Works

Providing whisper-quiet, zero-emission battery power for night-time rail and utility construction under strict European municipal noise regulations.

Night Noise

50 dB Silent Mode

CO2 Reduction

78% Cut

Chile MPMC Hybrid Power in Chile High-Altitude Mining

Chile • High-Altitude Copper Mining Camp

Operating continuously at 4,200m altitude in the Andes. Delivers stable 24/7 power for communication towers, surveillance, and remote worker accommodations.

Operating Alt.

4,200m ASL

Maintenance

1,000 hrs Cycle

Australia MPMC Hybrid Power Station in Australia Mining

Australia • Remote Pilbara Mining & Drill Rig

RCM certified hybrid power stations enduring 50°C ambient desert heat. Seamlessly absorbs heavy inductive motor startup surges with zero voltage sag.

Compliance

RCM Certified

Peak Ambient

50°C Tolerant

Middle East MPMC Hybrid Power in Middle East Oilfield

Middle East • Desert Oilfield & Pipeline Station

Dustproof IP54 heavy-gauge canopy engineered for sandstorm endurance. Integrated MPPT solar chargers maximize abundant desert sunlight for off-grid operations.

Protection

IP54 Heavy Enclosure

Fuel Cut

85% Saved

Global Events MPMC Hybrid Power at Global Major Events

Worldwide • Major Festivals & Sports Events

Supplying zero-flicker UPS-grade clean power for live broadcasting trucks, sound stages, and VIP pavilions with 0ms uninterrupted power changeover.

Switch Time

0 ms Seamless

Emissions

Zero Night Carbon
